Hi guys,

I'm holding out with the F-14D of VF-2 WIP as I'm building a F-14A+ (what the F-14B was originally called) of VF-74 'Bedevilers' during Desert Storm, 1991. I'm going to do an in flight Tomcat, kitted out with a near full complement of air-to-air ordnance (2x AIM-9L, 3x AIM-7M, 2x AIM-54C).
I'm hoping to save time with not having to do the undercarriage.

Enough waffle, here is the progress so far;

The kit and the VF-74 patches I want to mount on the display base


Aftermarket decals for VF-74 by Fightertown Decals of USA, and Master brass pitot and AOA


Reference material for the build


The cockpit so far. In the F-14D kit there are all the parts needed to make an A+, B or D model Tomcat.


The kit MB GRU-7 seats. They are actually quite good, and as I'll be putting the pilots in, I'm not going to bother with resin seats


The chaos of the modelling table!


Hope you guys are all enjoying the new year and making the most of all the modelling oppurtunities you can.

Parabat
